bbtk::Factory Class Reference

Can load and unload dynamic libraries containing black boxes packages and create instances of the black boxes registered in the packages loaded. More...

#include <bbtkFactory.h>

Inheritance diagram for bbtk::Factory:

[legend]

Collaboration diagram for bbtk::Factory:

[legend]

List of all members.

Public Types
enum	IndexEntryType { Packages, Categories, Initials, Adaptors }
typedef Factory	Self
typedef boost::shared_ptr< Self >	Pointer
typedef boost::weak_ptr< Self >	WeakPointer
typedef std::map< std::string, Package::Pointer >	PackageMapType
	The type of map of packages.
Public Member Functions
std::string	GetObjectName () const
std::string	GetObjectInfo () const
size_t	GetObjectSize () const
size_t	GetObjectInternalSize () const
size_t	GetObjectRecursiveSize () const
void	GetPackagesList (std::vector< std::string > &)
void	LoadPackage (const std::string &name)
	Loads a package.
void	UnLoadPackage (const std::string &name)
	UnLoads a package.
void	PrintPackages (bool details=true, bool adaptors=false) const
	Displays the list of packages loaded.
void	HelpPackage (const std::string &name, bool adaptors=false) const
	Displays help on a package.
void	HelpBlackBox (const std::string &name, std::string &package, bool full=true) const
void	ShowGraphTypes (const std::string &name) const
void	InsertPackage (Package::Pointer)
	Inserts a package in the factory.
void	RemovePackage (Package::Pointer)
	Removes a package from the factory (and deletes it).
Package::Pointer	GetPackage (const std::string &name) const
BlackBox::Pointer	NewBlackBox (const std::string &type, const std::string &name) const
	Creates an instance of a black box of type <type> with name <name>.
BlackBox::Pointer	NewAdaptor (const DataInfo &typein, const DataInfo &typeout, const std::string &name) const
	Creates an instance of a black box of type <type> with name <name>.
BlackBox::Pointer	NewWidgetAdaptor (const DataInfo &typein, const DataInfo &typeout, const std::string &name) const
	Creates an instance of a black box of type <type> with name <name>.
bool	FindAdaptor (const DataInfo &typein, const DataInfo &typeout, std::string &adaptor) const
	Creates an instance of a black box of type <type> with name <name>.
bool	FindWidgetAdaptor (const DataInfo &typein, const DataInfo &typeout, std::string &adaptor) const
	Creates an instance of a black box of type <type> with name <name>.
bool	FindWidgetAdaptor2 (const DataInfo &typein, const DataInfo &typeout, std::string &widget, std::string &adaptor) const
	Creates an instance of a black box of type <type> with name <name>.
Connection::Pointer	NewConnection (BlackBox::Pointer from, const std::string &output, BlackBox::Pointer to, const std::string &input) const
	Creates an instance of a connection.
void	WriteDotFilePackagesList (FILE *ff)
void	Reset ()
void	CheckPackages () const
void	CreateHtmlIndex (IndexEntryType type, const std::string &filename)
void	SetExecuter (ExecuterPointer e)
	Sets the executer who created the factory (if any).
ExecuterPointer	GetExecuter ()
	Gets the executer who created the factory (if any).
const PackageMapType &	GetPackageMap () const
long	GetUseCount ()
Static Public Member Functions
static Pointer	New ()
	Default ctor.
static void	InsertInObjectList (Pointer)
static void	RemoveFromObjectList (WeakPointer)
static void	InsertInPackageList (Pointer)
static void	ReleasePackages ()
static void	PrintObjectListInfo (const std::string &name)
static void	PrintObjectInfo (const Pointer &o)
static long	GetObjectsCount ()
Protected Types
typedef Object	Superclass
Protected Member Functions
	Factory ()
	Default ctor.
	Factory (const Factory &)
	~Factory ()
	Dtor.
void	LockThis ()
void	UnLockThis ()
template<class U>
boost::shared_ptr< U >	GetThisPointer () const
Static Protected Member Functions
template<class U>
static boost::shared_ptr< U >	MakePointer (U *s, bool lock=false)
template<class U, class D>
static boost::shared_ptr< U >	MakePointer (U *s, const D &del, bool lock=false)
Private Member Functions
bool	DoLoadPackage (std::string libname, std::string pkgname, std::string path)
	Gets the executer who created the factory (if any) - const.
void	CloseAllPackages ()
void	ClosePackage (PackageMapType::iterator &i)
	Close the package referenced by the iterator.
Private Attributes
PackageMapType	mPackageMap
	The map of packages.
ExecuterWeakPointer	mExecuter
	The executer which created the factory (if any).
Friends
struct	Object::Deleter

---

Detailed Description

Can load and unload dynamic libraries containing black boxes packages and create instances of the black boxes registered in the packages loaded.

Definition at line 53 of file bbtkFactory.h.

---

Member Typedef Documentation

typedef Factory bbtk::Factory::Self

Definition at line 55 of file bbtkFactory.h.

typedef boost::shared_ptr<Self> bbtk::Factory::Pointer

Reimplemented from bbtk::Object.

Definition at line 55 of file bbtkFactory.h.

typedef boost::weak_ptr<Self> bbtk::Factory::WeakPointer

Reimplemented from bbtk::Object.

Definition at line 55 of file bbtkFactory.h.

typedef Object bbtk::Factory::Superclass [protected]

Definition at line 55 of file bbtkFactory.h.

typedef std::map< std::string, Package::Pointer > bbtk::Factory::PackageMapType

The type of map of packages.

Definition at line 137 of file bbtkFactory.h.

---

Member Enumeration Documentation

enum bbtk::Factory::IndexEntryType

Enumerator:

Packages
Categories
Initials
Adaptors

Definition at line 110 of file bbtkFactory.h.

      {
        Packages,
        Categories,
        Initials,
        Adaptors
      }

---

Constructor & Destructor Documentation

bbtk::Factory::Factory

(

)

[protected]

Default ctor.

Definition at line 67 of file bbtkFactory.cxx.

References bbtkDebugMessage.

    : mExecuter()
  {
    bbtkDebugMessage("Kernel",7,"Factory::Factory()"<<std::endl);
  }

bbtk::Factory::Factory

(

const Factory &

)

[protected]

bbtk::Factory::~Factory

(

)

[protected]

Dtor.

Definition at line 76 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, and CloseAllPackages().

  {
    bbtkDebugMessageInc("Kernel",7,"Factory::~Factory()"<<std::endl);
    CloseAllPackages();
    bbtkDebugDecTab("Kernel",7);
  }

Here is the call graph for this function:

---

Member Function Documentation

std::string bbtk::Factory::GetObjectName

(

)

const [virtual]

Reimplemented from bbtk::Object.

Definition at line 1045 of file bbtkFactory.cxx.

  {
    return std::string("Factory");
  }

std::string bbtk::Factory::GetObjectInfo

(

)

const [virtual]

Reimplemented from bbtk::Object.

Definition at line 1052 of file bbtkFactory.cxx.

  {
    std::stringstream i;
    return i.str();
  }

size_t bbtk::Factory::GetObjectSize

(

)

const [virtual]

Reimplemented from bbtk::Object.

Definition at line 1060 of file bbtkFactory.cxx.

{
  size_t s = Superclass::GetObjectSize();
  s += Factory::GetObjectInternalSize();
  return s;
  }

size_t bbtk::Factory::GetObjectInternalSize

(

)

const [virtual]

Reimplemented from bbtk::Object.

Definition at line 1068 of file bbtkFactory.cxx.

{
  size_t s = sizeof(Factory);
  return s;
  }

size_t bbtk::Factory::GetObjectRecursiveSize

(

)

const [virtual]

Reimplemented from bbtk::Object.

Definition at line 1075 of file bbtkFactory.cxx.

References mPackageMap.

  {
    size_t s = Superclass::GetObjectRecursiveSize();
    s += Factory::GetObjectInternalSize();

    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
    {
      s += i->second->GetObjectRecursiveSize();
    }
    return s;
  }

Factory::Pointer bbtk::Factory::New

(

)

[static]

Default ctor.

Definition at line 58 of file bbtkFactory.cxx.

References bbtkDebugMessage, and bbtk::Object::MakePointer().

  {
    bbtkDebugMessage("Kernel",9,"Factory::New()"<<std::endl);
    return MakePointer(new Factory());
  }

Here is the call graph for this function:

void bbtk::Factory::GetPackagesList

(

std::vector< std::string > &

)

void bbtk::Factory::LoadPackage

(

const std::string &

name

)

Loads a package.

The name is the system-independant name of the package (the name of the instance of bbtk::Package). Tries to open the dynamic library :

• "libbb<name>.so" for linux systems,
• "bb<name>.dll" for windows systems. If it succeeds, then tries to load the symbols "<name>GetPackage" and "<name>DeletePackage". "<name>GetPackage" is called to get the pointer on the bbtk::Package of the library ("<name>DeletePackage" is not used, its presence is just checked before loading the package). now, filename is only the last name (no longer the full name!) it will be searched within *all* the paths given in bbtk_config.xml

Definition at line 140 of file bbtkFactory.cxx.

References bbtkDebugMessageInc, bbtkError, bbtkMessage, DoLoadPackage(), bbtk::i, and mPackageMap.

  {
  // Note : in the following :
  // name : the user supplied name
  //      - abreviated name    e.g.       pkg   pkg.so   libbpkg   libbbpkg.so
  //      - relative full name e.g.       ./libbbpkg.so   ../../libbbpkg.so
  //      - absolute full name e.g.       /home/usrname/proj/lib/libbbpkg.so
  //          same for Windows, with      c:, d: ...
  //
  // lastname : string before the last / (if any), or user supplied name

    bbtkDebugMessageInc("Kernel",7,"Factory::LoadPackage(\""<<name<<"\")"<<std::endl);
    bbtkMessage("debug",1,"Factory::LoadPackage(\""<<name<<"\")"<<std::endl);

    std::vector<std::string> package_paths;
    std::string libname;  // full path library name
    std::string pkgname;  // e.g. libbb<pkgname>.so

    std::string upath;
    pkgname = Utilities::ExtractPackageName(name,upath);

    bbtkMessage("debug",1,"Package name ["<<pkgname<<"]"<<std::endl);
    bbtkMessage("debug",1,"Package path ["<<upath<<"]"<<std::endl);

    // no loading package if already loaded
    PackageMapType::iterator iUnload;
    iUnload = mPackageMap.find(pkgname);
    if (iUnload != mPackageMap.end())
    {
      bbtkMessage("Output",2,"["<< pkgname <<"] already loaded" << std::endl);
      return;
    }

// =================================================
// The following structure was checked to work
// with any type of relative/absolute path.
// Please don't modify it without checking
// *all* the cases. JP
//==================================================

//std::cout << "upath [" << upath << "]" << std::endl;

    bool ok = false;
    bool foundFile = false;

    // If path provided by user will be the first scanned :
    // push it into vector of paths
    if (upath.length()>0)   // ------------------------------------- check user supplied location
    {
       if (name[0] != '.' && name[0] != '/' && name[1]!= ':')
       {
          bbtkError("Use absolute or relative path name! ["<<name<<"] is an illegal name");
          return;
       }

      // std::string path = Utilities::ExpandLibName(upath, false);
       std::string path = Utilities::ExpandLibName(name,false); // keep last item, here.

       if (path != "")
       {
          std::string p2;
          Utilities::ExtractPackageName(path,p2);
          //libname = Utilities::MakeLibnameFromPath(path, pkgname);
          libname = Utilities::MakeLibnameFromPath(p2, pkgname); // remove last item
          // Check if library exists
          if ( !Utilities::FileExists(libname) )
          {
          // The following is *NOT* a debug time message :
          // It's a user intended message.
          // Please don't remove it.
            bbtkMessage("Output",3,"   [" <<libname
                        <<"] : doesn't exist" <<std::endl);
          }
          else
          {
             ok = DoLoadPackage( libname, pkgname, path);
          }
       }
       else
       {
          bbtkError("Path ["<<upath<<"] doesn't exist");
          return;
       }
    }
    else     // ----------------------------------------------------- iterate on the paths
    {

    std::string path;
    package_paths = ConfigurationFile::GetInstance().Get_package_paths();
    std::vector<std::string>::iterator i;
    for (i=package_paths.begin();i!=package_paths.end();++i)
    {
        foundFile = false;
        path = *i;

        // we *really* want '.' to be the current working directory
        if (path == ".")
        {
          char buf[2048]; // for getcwd
          char * currentDir = getcwd(buf, 2048);
          std::string cwd(currentDir);
          path = currentDir;
        }

        libname = Utilities::MakeLibnameFromPath(path, pkgname);

        bbtkMessage("debug",2,"-> Trying to load [" << libname << "]" <<std::endl);

      // Check if library exists
        if ( !Utilities::FileExists(libname) )
        {
        // The following is *NOT* a debug time message :
        // It's a user intended message.
        // Please don't remove it.
          bbtkMessage("Output",3,
                      "   [" <<libname <<"] : doesn't exist" <<std::endl);
           continue;  // try next path
        }
        foundFile = true;

      // Try to Load the library

        ok = DoLoadPackage( libname, pkgname, path);
        if (ok)
        {
           bbtkMessage("debug",2,"   OK"<<std::endl);
        }
        break; // we stop iterating even if error : have to signal it to user
    } //------------------ // end for ( package_paths.begin();i!=package_paths.end() )

}

    if( !ok )  // nothing was loaded
    {
      if (!foundFile)
      {
        bbtkError("Could not find package ["<<pkgname<< "]");
      }
      else
      {
#if defined(__GNUC__)
        bbtkError("Could not load package ["<< pkgname
                  <<"] :" << std::endl
                  << "  Opening "<<libname<<" failed"
                  << "  Reason: "<< dlerror());
#elif defined(_WIN32)
        bbtkError("Could not load package ["<<pkgname
                  <<"] :"<< std::endl << "   Error loading " <<libname);

    // look how to get the error message on win
    //<<dlerror());
    // it is the bordel !! (the bloody fucking bordel, you mean?)
    // look : http://msdn2.microsoft.com/en-us/library/ms680582.aspx
#endif
      }
    }
    bbtkMessage("Output",2,"[" << libname << "] loaded" << std::endl);

  }

Here is the call graph for this function:

void bbtk::Factory::UnLoadPackage

(

const std::string &

name

)

UnLoads a package.

The package must have been previously loaded by LoadPackage. If the entry is found in the map, calls ClosePackage

Definition at line 305 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkError, ClosePackage(), bbtk::i, and mPackageMap.

 {
    bbtkDebugMessageInc("Kernel",7,"Factory::UnLoadPackage(\""
                       <<name<<"\")"<<std::endl);

    PackageMapType::iterator i;
    i = mPackageMap.find(name);
    if (i == mPackageMap.end())
    {
      bbtkError("cannot unload package \""<<name
                <<"\" : package not loaded !");
    }
    ClosePackage(i);
    bbtkDebugDecTab("Kernel",7);
  }

Here is the call graph for this function:

void bbtk::Factory::PrintPackages	(	bool	details = true,
		bool	adaptors = false
	)			const

Displays the list of packages loaded.

Definition at line 372 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkMessage, bbtk::i, and mPackageMap.

  {
    bbtkDebugMessageInc("Kernel",9,"Factory::PrintPackages"<<std::endl);

    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
    {
      bbtkMessage("Help",1, i->first << std::endl);
      if (details) {
         i->second->PrintBlackBoxes(false,adaptors);
      }
    }

    bbtkDebugDecTab("Kernel",9);
  }

void bbtk::Factory::HelpPackage	(	const std::string &	name,
		bool	adaptors = false
	)			const

Displays help on a package.

Definition at line 391 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkDecTab, bbtkError, bbtkIncTab, bbtkMessage, bbtkMessageCont, bbtk::i, and mPackageMap.

  {
    bbtkDebugMessageInc("Kernel",9,"Factory::HelpPackage(\""<<name<<"\")"
                        <<std::endl);

    PackageMapType::const_iterator i = mPackageMap.find(name);
    if ( i != mPackageMap.end() )
      {
      bbtkMessage("Help",1, "Package "<<i->first<<" ");

      if (i->second->GetVersion().length()>0)
        bbtkMessageCont("Help",1,"v" <<i->second->GetVersion());

      if (i->second->GetAuthor().length()>0)
        bbtkMessageCont("Help",1,"- "<<i->second->GetAuthor());

      if (i->second->GetCategory().length()>0)
        bbtkMessageCont("Help",1,"- "<<i->second->GetCategory());

      bbtkMessageCont("Help",1,std::endl);
      bbtkIncTab("Help",1);
      bbtkMessage("Help",1,i->second->GetDescription()<<std::endl);
      if (i->second->GetNumberOfBlackBoxes()>0)
        {
          bbtkMessage("Help",1, "Black boxes : "<<std::endl);
          i->second->PrintBlackBoxes(true,adaptors);
        }
      else
        {
          bbtkMessage("Help",1, "No black boxes"<<std::endl);
        }
      bbtkDecTab("Help",1);
      }
    else
      {
      bbtkDebugDecTab("Kernel",9);
      bbtkError("package \""<<name<<"\" unknown");
      }

    bbtkDebugDecTab("Kernel",9);
  }

void bbtk::Factory::HelpBlackBox	(	const std::string &	name,
		std::string &	package,
		bool	full = true
	)			const

Prints help on the black box of type <name> Returns the package to which it belongs

Definition at line 437 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkError, bbtk::i, and mPackageMap.

  {
    bbtkDebugMessageInc("Kernel",9,"Factory::HelpBlackBox(\""<<name<<"\")"
                        <<std::endl);

    bool found = false;
    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
      {
      if (i->second->ContainsBlackBox(name))
        {
          i->second->HelpBlackBox(name,full);
              package = i->second->GetName();
          found = true;
        }
      }

    bbtkDebugDecTab("Kernel",9);
    if (!found)
      {
      bbtkError("No package of the factory contains any black box <"
                 <<name<<">");
      }
  }

void bbtk::Factory::ShowGraphTypes

(

const std::string &

name

)

const

Definition at line 806 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkError, and mPackageMap.

 {

   bool found = false;
   PackageMapType::const_iterator i;
   for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
   {
      if (i->second->ContainsBlackBox(name))
      {
         std::string separator = ConfigurationFile::GetInstance().Get_file_separator ();

            // Don't pollute the file store with  "temp_dir" directories ...
         std::string default_doc_dir = ConfigurationFile::GetInstance().Get_default_temp_dir();
         std::string directory = "\"" + default_doc_dir + separator + "temp_dir"  +separator + "\"";
         std::string filename2 =  default_doc_dir + separator + "temp_dir" + separator + "tmp.html";

#if defined(_WIN32)
        std::string command("start \"Titre\" /D ");
#else
        std::string command("gnome-open ");
#endif
        command=command + directory +" tmp.html";
        FILE *ff;
        ff=fopen(filename2.c_str(),"w");

        fprintf(ff,"<html><head><title>TMP</title> <script type=\"text/javascript\"> <!--\n");
        fprintf(ff,"  window.location=\"%s#%s\";\n" , i->second->GetDocURL().c_str(),name.c_str() );
        fprintf(ff,"//--></script></head><body></body></html>\n");


        //fprintf(ff, "<a  href=\"%s#%s\">Link</a>\n", i->second->GetDocURL().c_str(),name.c_str() );
        fclose(ff);
        system( command.c_str() );
        found = true;
     }
   }

   bbtkDebugDecTab("Kernel",9);
   if (!found)
   {
      bbtkError("No package of the factory contains any black box <"
                <<name<<">");
   }
 }

void bbtk::Factory::InsertPackage

(

Package::Pointer

p

)

Inserts a package in the factory.

Definition at line 468 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, and mPackageMap.

  {
    bbtkDebugMessageInc("Kernel",9,"Factory::InsertPackage(\""<<
                        p->GetName()<<"\")"<<std::endl);

    p->AddFactory(GetThisPointer<Factory>());
    mPackageMap[p->GetName()] = p;

    bbtkDebugDecTab("Kernel",9);
  }

void bbtk::Factory::RemovePackage

(

Package::Pointer

p

)

Removes a package from the factory (and deletes it).

Definition at line 482 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkError, ClosePackage(), and mPackageMap.

  {
    bbtkDebugMessageInc("Kernel",9,"Factory::RemovePackage(\""<<
                        p->GetName()<<"\")"<<std::endl);

    PackageMapType::iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
      {
         if (i->second == p) break;
      };

    if (i!=mPackageMap.end())
      {
        ClosePackage(i);
      }
    else
      {
        bbtkError("Factory::RemovePackage(\""<<
                  p->GetName()<<"\") : package absent from factory");
      }

    bbtkDebugDecTab("Kernel",9);
  }

Here is the call graph for this function:

Package::Pointer bbtk::Factory::GetPackage

(

const std::string &

name

)

const

Definition at line 742 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkError, and mPackageMap.

Referenced by WriteDotFilePackagesList().

  {
    bbtkDebugMessageInc("Kernel",9,"Factory::GetPackage(\""<<name<<"\")"
                         <<std::endl);

    PackageMapType::const_iterator i = mPackageMap.find(name);
    if ( i != mPackageMap.end() )
    {
      bbtkDebugDecTab("Kernel",9);
      return i->second;
    }
    else
    {
       bbtkDebugDecTab("Kernel",9);
       bbtkError("package \""<<name<<"\" unknown");
    }

    bbtkDebugDecTab("Kernel",9);
  }

Here is the caller graph for this function:

BlackBox::Pointer bbtk::Factory::NewBlackBox	(	const std::string &	type,
		const std::string &	name
	)			const

Creates an instance of a black box of type <type> with name <name>.

Definition at line 510 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkError, and mPackageMap.

  {
    bbtkDebugMessageInc("Kernel",7,"Factory::NewBlackBox(\""
                        <<type<<"\",\""<<name<<"\")"<<std::endl);

    BlackBox::Pointer b;
    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
      {
      b = i->second->NewBlackBox(type,name);
      if (b) break;
      }
    if (!b)
      {
       bbtkError("black box type \""<<type<<"\" unknown");
      }

    bbtkDebugDecTab("Kernel",7);
    return b;
  }

BlackBox::Pointer bbtk::Factory::NewAdaptor	(	const DataInfo &	typein,
		const DataInfo &	typeout,
		const std::string &	name
	)			const

Creates an instance of a black box of type <type> with name <name>.

Definition at line 535 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkendl, bbtkError, and mPackageMap.

  {
    bbtkDebugMessageInc("Kernel",8,"Factory::NewAdaptor("
                        <<typein<<","
                        <<typeout<<",\""
                        <<name<<"\")"<<bbtkendl);


    BlackBox::Pointer b;
    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
      {
      b = i->second->NewAdaptor(typein,typeout,name);
      if (b) break;
      }
    if (!b)
      {
        bbtkError("no "<<typein<<" to "<<typeout
                  <<" adaptor available");
      }

    bbtkDebugDecTab("Kernel",7);
    return b;
  }

BlackBox::Pointer bbtk::Factory::NewWidgetAdaptor	(	const DataInfo &	typein,
		const DataInfo &	typeout,
		const std::string &	name
	)			const

Creates an instance of a black box of type <type> with name <name>.

Definition at line 566 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkendl, bbtkError, and mPackageMap.

  {
    bbtkDebugMessageInc("Kernel",8,"Factory::NewWidgetAdaptor(<"
                        <<typein<<">,<"
                        <<typeout<<">,\""
                        <<name<<"\")"<<bbtkendl);


    BlackBox::Pointer b;
    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
      {
        b = i->second->NewWidgetAdaptor(typein,
                                                 typeout,
                                                 name);
      if (b) break;
      }
    if (!b)
      {
        bbtkError("no "<<typein<<" to "<<typeout
                  <<"> widget adaptor available");
      }

    bbtkDebugDecTab("Kernel",7);
    return b;
  }

bool bbtk::Factory::FindAdaptor	(	const DataInfo &	typein,
		const DataInfo &	typeout,
		std::string &	adaptor
	)			const

Creates an instance of a black box of type <type> with name <name>.

Definition at line 598 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkendl, and mPackageMap.

Referenced by FindWidgetAdaptor2().

  {
    bbtkDebugMessageInc("Kernel",8,"Factory::FindAdaptor(<"
                        <<typein<<">,<"
                        <<typeout<<">)"<<bbtkendl);

    bool b = false;
    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
      {
        b = i->second->FindAdaptor(typein,
                                            typeout,
                                            adaptor);
        if (b) break;
      }
    /*
    if (!b)
      {
        bbtkError("no "<<typein<<" to "<<typeout
                  <<"> widget adaptor available");
      }
    */

    bbtkDebugDecTab("Kernel",7);
    return b;
  }

Here is the caller graph for this function:

bool bbtk::Factory::FindWidgetAdaptor	(	const DataInfo &	typein,
		const DataInfo &	typeout,
		std::string &	adaptor
	)			const

Creates an instance of a black box of type <type> with name <name>.

Definition at line 630 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkendl, and mPackageMap.

  {
    bbtkDebugMessageInc("Kernel",8,"Factory::FindWidgetAdaptor(<"
                        <<typein<<">,<"
                        <<typeout<<">)"<<bbtkendl);

    bool b = false;
    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
      {
        b = i->second->FindWidgetAdaptor(typein,
                                                  typeout,
                                                  adaptor);
        if (b) break;
      }
    bbtkDebugDecTab("Kernel",7);
    return b;
  }

bool bbtk::Factory::FindWidgetAdaptor2	(	const DataInfo &	typein,
		const DataInfo &	typeout,
		std::string &	widget,
		std::string &	adaptor
	)			const

Creates an instance of a black box of type <type> with name <name>.

Definition at line 654 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, bbtkendl, bbtkMessage, FindAdaptor(), bbtk::DataInfo::GetNature(), bbtk::DataInfo::GetType(), and mPackageMap.

  {
    bbtkDebugMessageInc("Kernel",8,"Factory::FindWidgetAdaptor(<"
                        <<typein<<">,<"
                        <<typeout<<">)"<<bbtkendl);

    bool b = false;
    adaptor = widget = "";
    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
      {
        b = i->second->FindWidgetAdaptor(typein,
                                                  typeout,
                                                  widget);
        if (b) break;
      }
    if (!b)
      {
        // Look for a widget adaptor with good nature out
        bbtkMessage("Kernel",5,
                    "*** Looking for a two pieces widget adaptor for : "
                    << typein << "->"<<typeout<<std::endl);
        for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
          {
            Package::AdaptorMapType::const_iterator j;
            for (j=i->second->GetAdaptorMap().begin();
                 j!=i->second->GetAdaptorMap().end();
                 ++j)
              {
                if ( ( j->first.mKind ==
                       BlackBoxDescriptor::DEFAULT_GUI) &&
                     //(j->first.mTypeIn == typein) &&
                     (j->first.mTypeOut.GetNature() == typeout.GetNature() )
                     )
                  {
                    widget = j->second.lock()->GetTypeName();
                    bbtkMessage("Kernel",5,
                                "===> Found first part : "<<widget
                                << " "<<j->first.mTypeIn<<"->"
                                <<j->first.mTypeOut<<std::endl);
                    DataInfo ti( j->first.mTypeOut.GetType(), "");
                    DataInfo to( typeout.GetType(), "");
                    b = FindAdaptor( ti, to, adaptor );
                    if (b)
                      {
                        bbtkMessage("Kernel",5,
                                    "===> Found second part : "<<adaptor
                                    <<std::endl);
                        break;
                      }
                    else
                      {
                        bbtkMessage("Kernel",5,
                                    "===> No second part found"<<std::endl);
                      }
                  }
              }
            if (b) break;
          }
      }
    bbtkDebugDecTab("Kernel",7);
    return b;
  }

Here is the call graph for this function:

Connection::Pointer bbtk::Factory::NewConnection	(	BlackBox::Pointer	from,
		const std::string &	output,
		BlackBox::Pointer	to,
		const std::string &	input
	)			const

Creates an instance of a connection.

Definition at line 724 of file bbtkFactory.cxx.

References bbtkDebugMessage.

  {
    bbtkDebugMessage("Kernel",7,"Factory::NewConnection(\""
                      <<from->bbGetName()<<"\",\""<<output<<"\",\""
                      <<to->bbGetName()<<"\",\""<<input
                      <<"\")"<<std::endl);

    return Connection::New(from,output,to,input,
                           GetThisPointer<Factory>());
  }

void bbtk::Factory::WriteDotFilePackagesList

(

FILE *

ff

)

Definition at line 780 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, GetPackage(), and mPackageMap.

  {

    bbtkDebugMessageInc("Kernel",9,"Factory::WriteDotFilePackagesList()"
                         <<std::endl);

    fprintf( ff , "\n");
    fprintf( ff , "subgraph cluster_FACTORY {\n");
    fprintf( ff , "  label = \"PACKAGES\"%s\n",  ";");
    fprintf( ff , "  style=filled%s\n",";");
    fprintf( ff , "  color=lightgrey%s\n",";");
    fprintf( ff , "  rankdir=TB%s\n",";");

    std::string url;
    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
    {
       url=GetPackage(i->first)->GetDocURL();
       fprintf(ff,"  %s [shape=ellipse, URL=\"%s\"]%s\n",i->first.c_str(),url.c_str(),";" );
    }
    fprintf( ff , "}\n\n");
    bbtkDebugDecTab("Kernel",9);
  }

Here is the call graph for this function:

void bbtk::Factory::Reset

(

)

Definition at line 87 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, and CloseAllPackages().

  {
    bbtkDebugMessageInc("Kernel",7,"Factory::Reset()"<<std::endl);
    CloseAllPackages();
    bbtkDebugDecTab("Kernel",7);
  }

Here is the call graph for this function:

void bbtk::Factory::CheckPackages

(

)

const

Definition at line 765 of file bbtkFactory.cxx.

References bbtkMessage, and mPackageMap.

  {
    bbtkMessage("debug",1,"****** Checking Factory "<<(void*)this
                 <<std::endl);
    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
      {
        i->second->CheckBoxes();
      }
    bbtkMessage("debug",1,"****** Checking Factory "<<(void*)this
                <<" ... OK"<<std::endl);
  }

void bbtk::Factory::CreateHtmlIndex	(	IndexEntryType	type,
		const std::string &	filename
	)

Definition at line 854 of file bbtkFactory.cxx.

References Adaptors, bbtkDebugDecTab, bbtkDebugMessageInc, bbtkendl, bbtkError, Categories, Initials, mPackageMap, and Packages.

  {
    bbtkDebugMessageInc("Kernel",9,"Factory::CreateHtmlIndex(\""
                        <<filename<<"\")"<<bbtkendl);

    std::string title;

    typedef std::map<std::string,
      std::vector<BlackBoxDescriptor::Pointer> > IndexType;
    IndexType index;
    // Builds the index map
    PackageMapType::const_iterator i;
    for (i = mPackageMap.begin(); i!=mPackageMap.end(); ++i )
      {
        Package::Pointer pack = i->second;
        if (pack->GetName()=="user") continue;
        Package::BlackBoxMapType::const_iterator j;
        for (j = pack->GetBlackBoxMap().begin();
             j!= pack->GetBlackBoxMap().end();
             ++j)
          {

            // Skip adaptors
            if ( type==Adaptors )
              {
                if (j->second->GetKind() == BlackBoxDescriptor::STANDARD )
                  continue;
              }
            else
              if (j->second->GetKind() != BlackBoxDescriptor::STANDARD )
                continue;

            std::vector<std::string> keys;
            if (type==Packages)
              {
                std::string k("");
                k += pack->GetName();
                keys.push_back(k);
                title = "Boxes by package";
              }
            else if ((type==Initials) || (type==Adaptors))
              {
                std::string init(" ");
                init[0] =  std::toupper(j->second->GetTypeName()[0]);
                keys.push_back(init);
                title = "Alphabetical list";
              }
            else if (type==Categories)
              {
                // Split the category string
                std::string delimiters = ";,";
                Utilities::SplitString(j->second->GetCategory(),
                                       delimiters,keys);
                if (keys.size()==0)
                  keys.push_back(" NONE");
                title = "Boxes by category";
              }


            std::vector<std::string>::const_iterator k;
            for (k=keys.begin(); k!=keys.end(); ++k )
              {
                IndexType::iterator p;
                p = index.find(*k);
                if (p != index.end())
                  {
                    p->second.push_back(j->second);
                  }
                else
                  {
                    std::vector<BlackBoxDescriptor::Pointer> v;
                    v.push_back(j->second);
                    index[*k] = v;
                  }
              }

          }
      }
    // Creates the file
    //---------------------
    // Open output file
    std::ofstream s;
    s.open(filename.c_str());
    if (!s.good())
    {
       bbtkError("Factory::CreateHtmlIndex : could not open file '"
                 <<filename<<"'");
    }

    //----------------------
    // Html head
    s << "<html lang=\"en\">\n";
    s << "<head>\n";
    s << "<title>"<<title<<"</title>\n";
    s << "<meta http-equiv=\"Content-Type\" content=\"text/html\">\n";
    s << "<meta name=\"description\" content=\""<<title<<"\">\n";
    s << "<meta name=\"generator\" content=\"\">\n";
    s << "<link title=\"Top\" rel=\"top\" href=\"#Top\">\n";
    //<link href="http://www.gnu.org/software/texinfo/" rel="generator-home" title="Texinfo Homepage">
    s << "<meta http-equiv=\"Content-Style-Type\" content=\"text/css\"><style type=\"text/css\"><!--\n";
    s << "pre.display { font-family:inherit }\n";
    s << "pre.format  { font-family:inherit }\n";
    s << "pre.smalldisplay { font-family:inherit; font-size:smaller }\n";
    s << "pre.smallformat  { font-family:inherit; font-size:smaller }\n";
    s << "pre.smallexample { font-size:smaller }\n";
    s << "pre.smalllisp    { font-size:smaller }\n";
    s << "span.sc    { font-variant:small-caps }\n";
    s << "span.roman { font-family:serif; font-weight:normal; } \n";
    s << "span.sansserif { font-family:sans-serif; font-weight:normal; }\n";
    s << "--></style>\n";
    s << "</head>\n";
    //----------------------

    //----------------------
    // Html body
    s << "<body>\n";
    s << "<a name=\"Top\"></a>\n";
    s << "<h1 class=\"settitle\">"<<title<<"</h1>\n";
    s << "<p>\n";
    IndexType::iterator ii;
    for (ii=index.begin();ii!=index.end();++ii)
      {
        s << "<a href=\"#"<<ii->first<<"\">"<<ii->first<<"</a>&nbsp;&nbsp;";
      }

    for (ii=index.begin();ii!=index.end();++ii)
      {
        s << "<p><hr>\n";
        s << "<p><a href=\"#Top\">Top</a>";
        if (type==Packages)
          {
            s << "<a name=\""<<ii->first<<"\"></a>\n";
            s << "<p><a href=\""<<ii->first<<"/index.html\">"
              << ii->first<<"</a>\n";

            s << "&nbsp;&nbsp;-&nbsp;&nbsp;\n";

            s << "<a name=\"doxygen\"></a>\n";
            s << "<a href=..\\doxygen\\" << ii->first << "/main.html>(Doxygen documentation of the source)</a>\n";
          }
        else
          {
            s << "<a name=\""<<ii->first<<"\"></a>\n";
            s << "<p><b>"<<ii->first<<"</b>\n";
          }
        s << "<ul>\n";

        s << "<p><TABLE cellspacing=0  cellpadding=3>\n";

        std::vector<BlackBoxDescriptor::Pointer>::iterator di;
        for (di=ii->second.begin();di!=ii->second.end();++di)
          {
            std::string pack = (*di)->GetPackage()->GetName();
            std::string name = (*di)->GetTypeName();
            Utilities::html_format(name);
            std::string descr = (*di)->GetDescription();
            Utilities::html_format(descr);
            s << "<TR>";
            s << "<TD style='vertical-align: top;'>";
            s << "&nbsp;&nbsp;&nbsp;<a href=\""<<pack
              <<"/index.html#"<<name<<"\">"
              <<pack<<"::"<<name<<"</a>";
            s << "</TD> ";
            s << " <TD style='vertical-align: top;'>" << descr << " </TD>";
            s << "</TR>\n";
          }
        s << "</TABLE>\n";
        s << "</ul>\n";
        s << "</div>\n";
      }
    //----------------------
    // Footer
    time_t rawtime;
    tm * ptm;
    time ( &rawtime );
    ptm = gmtime ( &rawtime );

    s << "<p><hr>\n";
    s << "Automatically generated by <b>bbtk</b> on "
      << ptm->tm_mday << "/" << ptm->tm_mon << "/" << ptm->tm_year+1900
      << " - " << ptm->tm_hour << ":" << ptm->tm_min << " GMT\n";
    s << "</body></html>\n";
    s.close();
    //----------------------

    // End
    bbtkDebugDecTab("Kernel",9);
  }

void bbtk::Factory::SetExecuter

(

ExecuterPointer

e

)

[inline]

Sets the executer who created the factory (if any).

Definition at line 121 of file bbtkFactory.h.

{ mExecuter = e; }

ExecuterPointer bbtk::Factory::GetExecuter

(

)

[inline]

Gets the executer who created the factory (if any).

Definition at line 123 of file bbtkFactory.h.

{ return mExecuter.lock(); }

bool bbtk::Factory::DoLoadPackage	(	std::string	libname,
		std::string	pkgname,
		std::string	path
	)			[private]

Gets the executer who created the factory (if any) - const.

Definition at line 97 of file bbtkFactory.cxx.

References bbtkMessage, and mPackageMap.

Referenced by LoadPackage().

  {

    Package::Pointer p = Package::CreateFromDynamicLibrary(libname,
                                                           pkgname,
                                                           path);
    if (p!=0)
      {
        //===================================================================
        bbtkMessage("Output",2,p->GetName()<<" "
                    <<p->GetVersion()
                    <<" "
                    <<p->GetAuthor() << " Category(s) :"
                    <<p->GetCategory()
                    <<std::endl);
        bbtkMessage("Output",2,p->GetDescription()<<std::endl);
        //===================================================================
        p->AddFactory(GetThisPointer<Factory>());
        mPackageMap[pkgname] = p;
        return true;
      }
    return false;

  }

Here is the caller graph for this function:

const PackageMapType& bbtk::Factory::GetPackageMap

(

)

const [inline]

Definition at line 139 of file bbtkFactory.h.

{ return mPackageMap; }

void bbtk::Factory::CloseAllPackages

(

)

[private]

Definition at line 324 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, ClosePackage(), bbtk::i, and mPackageMap.

Referenced by Reset(), and ~Factory().

  {
    bbtkDebugMessageInc("Kernel",7,"Factory::CloseAllPackages()"<<std::endl);
    while (mPackageMap.begin() != mPackageMap.end())
      {
        PackageMapType::iterator i = mPackageMap.begin();
        ClosePackage(i);
      }
    bbtkDebugDecTab("Kernel",7);
  }

Here is the call graph for this function:

Here is the caller graph for this function:

void bbtk::Factory::ClosePackage

(

PackageMapType::iterator &

i

)

[private]

Close the package referenced by the iterator.

First removes the factory from the set of factories which use the package If the set is empty then : If it is a dynamically loaded package :

• Loads and calls the function "<name>DeletePackage" of the dynamic library (responsible for package desallocation)
• Closes the dynamic library Else :
• deletes the package normally

Finally erases the package entry in the packages map

Definition at line 348 of file bbtkFactory.cxx.

References bbtkDebugDecTab, bbtkDebugMessageInc, and mPackageMap.

Referenced by CloseAllPackages(), RemovePackage(), and UnLoadPackage().

  {
     bbtkDebugMessageInc("Kernel",7,"Factory::ClosePackage(\""
                         <<i->second->GetName()
                        <<"\")"<<std::endl);


     // Removes this from the set of factories which use the package
     i->second->RemoveFactory(GetThisPointer<Factory>());
     Package::WeakPointer p = i->second;
     // remove the entry in the map
     mPackageMap.erase(i);
     // Release the package if not already destroyed
     if (p.lock()) Package::Release(p);


     bbtkDebugDecTab("Kernel",7);
  }

Here is the caller graph for this function:

long bbtk::Object::GetUseCount

(

)

[inline, inherited]

Definition at line 63 of file bbtkObject.h.

{ return mThisPointer.use_count(); }

void bbtk::Object::InsertInObjectList

(

Pointer

p

)

[static, inherited]

Definition at line 59 of file bbtkObject.cxx.

References bbtkDebugMessage, and bbtk::Object::mgObjectList.

  {
    bbtkDebugMessage("object",9,"##> Object::InsertInObjectList(\""
                     <<p->GetObjectName()<<"\" ["<<p<<"])"<<std::endl);
    boost::weak_ptr<Object> w(p);
    mgObjectList.insert(w);
  }

void bbtk::Object::RemoveFromObjectList

(

WeakPointer

p

)

[static, inherited]

Definition at line 80 of file bbtkObject.cxx.

References bbtkDebugMessage, and bbtk::Object::mgObjectList.

  {
    bbtkDebugMessage("object",9,"##> Object::RemoveFromObjectList()"
                     <<std::endl);
    mgObjectList.erase(p);

  }

void bbtk::Object::InsertInPackageList

(

Pointer

p

)

[static, inherited]

Definition at line 69 of file bbtkObject.cxx.

References bbtkDebugMessage, and bbtk::Object::mgPackageList.

  {
    bbtkDebugMessage("object",9,"##> Object::InsertInPackageList(\""
                     <<p->GetObjectName()<<"\" ["<<p<<"])"<<std::endl);
    boost::weak_ptr<Object> w(p);
    mgPackageList.insert(w);
  }

void bbtk::Object::ReleasePackages

(

)

[static, inherited]

Definition at line 213 of file bbtkObject.cxx.

References bbtkDebugMessage, bbtk::i, and bbtk::Object::mgPackageList.

  {
    bbtkDebugMessage("object",1,"##> Object::ReleasePackages()"<<std::endl);
    // Release package pointers
    ObjectListType::iterator i;
    for (i = mgPackageList.begin();
         i!= mgPackageList.end();
         ++i)
      {
        if (i->use_count() != 0)
          {
            bbtkDebugMessage("object",1,"##> Releasing package '"<<
                             i->lock()->GetThisPointer<Package>()->GetName()
                             <<"'"<<std::endl);
            //      Object::Pointer p(i->lock());
            Package::WeakPointer w(i->lock()->GetThisPointer<Package>());
            Package::Release(w);
            /*
            if (p->GetObjectName().find(name) != std::string::npos )
              {
                std::cout << n << "/" << mgObjectList.size() << " ";
                PrintObjectInfo(p);
                m += p->GetObjectSize();
                n++;
              }
            */
          }
      }

  }

void bbtk::Object::PrintObjectListInfo

(

const std::string &

name

)

[static, inherited]

Definition at line 105 of file bbtkObject.cxx.

References bbtk::i, bbtk::Object::mgObjectList, and bbtk::Object::PrintObjectInfo().

  {

    std::cout
      << "=============== Living bbtk::Object pointers ========="<<std::endl;

    long n = 0;
    long u = 0;
    size_t m = 0;
    ObjectListType::iterator i;
    for (i = mgObjectList.begin();
         i!=mgObjectList.end();
         ++i)
      {
        if (i->use_count() == 0)
          {
            u++;
          }
        else
          {
            Object::Pointer p(i->lock());
            if (p->GetObjectName().find(name) != std::string::npos )
              {
                std::cout << n << "/" << mgObjectList.size() << " ";
                PrintObjectInfo(p);
                m += p->GetObjectSize();
                n++;
              }
          }
      }
    std::cout
      << "------------------------------------------------------"<<std::endl;

    std::cout << " Total : "<<n<<" objects - "<<m<<" b"<<std::endl;
    if (u==1)
      {
        std::cout<<"* Note : "<<u
                 <<" object in list has 0 ref count, "
                 <<"i.e. destroyed without removing itself from the living objects list ! (this is just an implementation error not a memory leak)"<<std::endl;
      }
    else if (u>1)
      {
        std::cout<<"* Note : "<<u
                 <<" objects in list have 0 ref count, "
                 <<"i.e. destroyed without removing themselves from the living objects list ! (this is just an implementation error not a memory leak)"<<std::endl;
      }
    std::cout
      << "============ EO Living bbtk::Object pointers ========="<<std::endl;

  }

Here is the call graph for this function:

void bbtk::Object::PrintObjectInfo

(

const Pointer &

o

)

[static, inherited]

Definition at line 180 of file bbtkObject.cxx.

Referenced by bbtk::Object::PrintObjectListInfo().

  {
    std::cout << "* [" << p << "] \t"
              << p.use_count()-1 << " r \t"
              << p->GetObjectRecursiveSize() << " ("
              << p->GetObjectSize() << ") b \t"
              << p->GetObjectName()
              << std::endl;
    std::cout << p->GetObjectInfo();
  }

Here is the caller graph for this function:

static long bbtk::Object::GetObjectsCount

(

)

[inline, static, inherited]

Definition at line 75 of file bbtkObject.h.

{ return mgObjectList.size(); }

void bbtk::Object::LockThis

(

)

[inline, protected, inherited]

Definition at line 88 of file bbtkObject.h.

{ mThisPointerLocked = mThisPointer.lock(); }

void bbtk::Object::UnLockThis

(

)

[inline, protected, inherited]

Definition at line 89 of file bbtkObject.h.

{ mThisPointerLocked = Pointer(); }

template<class U>

boost::shared_ptr<U> bbtk::Object::GetThisPointer

(

)

const [inline, protected, inherited]

Definition at line 92 of file bbtkObject.h.

    {
      return boost::dynamic_pointer_cast<U>(mThisPointer.lock());
    }

template<class U>

static boost::shared_ptr<U> bbtk::Object::MakePointer	(	U *	s,
		bool	lock = false
	)			[inline, static, protected, inherited]

Definition at line 97 of file bbtkObject.h.

Referenced by bbtk::Executer::Executer(), bbtk::Interpreter::Init(), bbtk::Transcriptor::New(), bbtk::Package::New(), bbtk::Interpreter::New(), New(), and bbtk::Executer::New().

    {
      if (s->mThisPointer.lock())
        {
          boost::shared_ptr<U> p = s->GetThisPointer<U>();
          if (!lock) s->mThisPointerLocked.reset();
          return p;
        }
      boost::shared_ptr<U> p = boost::shared_ptr<U>(s,Object::Deleter());
      static_cast<Object::Deleter*>
        (p._internal_get_deleter(typeid(Object::Deleter)))
        ->mPointer = p;
      s->mThisPointer = p;
      Object::InsertInObjectList(p);
      if (lock) s->LockThis();
      return p;
    }

Here is the caller graph for this function:

template<class U, class D>

static boost::shared_ptr<U> bbtk::Object::MakePointer	(	U *	s,
		const D &	del,
		bool	lock = false
	)			[inline, static, protected, inherited]

Definition at line 115 of file bbtkObject.h.

    {
      if (s->mThisPointer.lock())
        {
          boost::shared_ptr<U> p = s->GetThisPointer<U>();
          if (!lock) s->mThisPointerLocked.reset();
          return p;
        }
      boost::shared_ptr<U> p = boost::shared_ptr<U>(s,del);
      static_cast<D*>
        (p._internal_get_deleter(typeid(D)))
        ->mPointer = p;
      s->mThisPointer = p;
      Object::InsertInObjectList(p);
      if (lock) s->LockThis();
      return p;
    }

---

Friends And Related Function Documentation

friend struct Object::Deleter [friend]

Definition at line 55 of file bbtkFactory.h.

---

Member Data Documentation

PackageMapType bbtk::Factory::mPackageMap [private]

The map of packages.

Definition at line 143 of file bbtkFactory.h.

Referenced by CheckPackages(), CloseAllPackages(), ClosePackage(), CreateHtmlIndex(), DoLoadPackage(), FindAdaptor(), FindWidgetAdaptor(), FindWidgetAdaptor2(), GetObjectRecursiveSize(), GetPackage(), HelpBlackBox(), HelpPackage(), InsertPackage(), LoadPackage(), NewAdaptor(), NewBlackBox(), NewWidgetAdaptor(), PrintPackages(), RemovePackage(), ShowGraphTypes(), UnLoadPackage(), and WriteDotFilePackagesList().

ExecuterWeakPointer bbtk::Factory::mExecuter [private]

The executer which created the factory (if any).

Definition at line 146 of file bbtkFactory.h.

---

The documentation for this class was generated from the following files:

• /home/guigues/bbtk-build-tmp/bbtk/kernel/src/bbtkFactory.h
• /home/guigues/bbtk-build-tmp/bbtk/kernel/src/bbtkFactory.cxx
