creaImageIO::MultiThreadImageReader Class Reference

00033       {
00034         ThreadedReaderStarted,
00035         ThreadedReaderStopped,
00036         ImageLoaded,
00037         ImageUnloaded,
00038         Error
00039       }

Constructor & Destructor Documentation

creaImageIO::MultiThreadImageReader::MultiThreadImageReader ( int number_of_threads = 1 )

Ctor with the number of threads to use.

creaImageIO::MultiThreadImageReader::~MultiThreadImageReader ( )

Dtor.

Member Function Documentation

bool creaImageIO::MultiThreadImageReader::Start ( )

Starts the reader = create the threads which start to check periodically the queue of requested images to read

void creaImageIO::MultiThreadImageReader::Stop ( )

Stops the reader = stops the threads and delete the images loaded.

void creaImageIO::MultiThreadImageReader::Request	(	MultiThreadImageReaderUser *	user,
		const std::string &	filename,
		int	priority
	)

Request the image "filename" with a given priority When the image is ready (or an error occurred) The observer's callback is invoked

vtkImageData* creaImageIO::MultiThreadImageReader::GetImage ( const std::string & filename )

(no user callback but image returned)

Request the image "filename" immediately Blocks until image loaded

Referenced by creaImageIO::GimmickView::GetDefaultImage().

Here is the caller graph for this function:

int creaImageIO::MultiThreadImageReader::GetMaximalPriority ( )

Referenced by creaImageIO::GimmickView::GetMaximalPriority().

Here is the caller graph for this function:

void creaImageIO::MultiThreadImageReader::OnMultiThreadImageReaderEvent	(	const std::string &	filename,
		EventType	type,
		vtkImageData *	image
	)			`[virtual]`

The virtual method to overload by MultiThreadImageReader users It is called when an image has been loaded or unloaded Provides : The image file name which was requested The type of event If type==ImageLoaded the image pointer, else NULL pointer

Reimplemented from creaImageIO::MultiThreadImageReaderUser.

int creaImageIO::MultiThreadImageReader::GetMaximalPriorityWithoutLocking ( ) [protected]

void creaImageIO::MultiThreadImageReader::SignalImageRead	(	ImageToLoadPtr	p,
		bool	purge
	)			`[protected]`

The callback from threaded readers when an image is read.

void creaImageIO::MultiThreadImageReader::UpdateUnloadPriority	(	ImageToLoadPtr	p,
		int	priority
	)			`[protected]`

void creaImageIO::MultiThreadImageReaderUser::MultiThreadImageReaderEventLock ( ) [inline, inherited]

Definition at line 51 of file creaImageIOMultiThreadImageReader.h.

00052     { mMultiThreadImageReaderUserMutex.Lock(); }

void creaImageIO::MultiThreadImageReaderUser::MultiThreadImageReaderEventUnlock ( ) [inline, inherited]

Definition at line 53 of file creaImageIOMultiThreadImageReader.h.

00054     { mMultiThreadImageReaderUserMutex.Unlock(); }

wxMutex& creaImageIO::MultiThreadImageReaderUser::GetMultiThreadImageReaderUserMutex ( ) [inline, inherited]

Definition at line 55 of file creaImageIOMultiThreadImageReader.h.

00056     { return mMultiThreadImageReaderUserMutex; }

Friends And Related Function Documentation

friend class ThreadedImageReader [friend]

Reimplemented from creaImageIO::MultiThreadImageReaderUser.

Definition at line 74 of file creaImageIOMultiThreadImageReader.h.

friend class MultiThreadImageReader [friend, inherited]

Definition at line 27 of file creaImageIOMultiThreadImageReader.h.

Member Data Documentation

ImageMapType creaImageIO::MultiThreadImageReader::mImages [protected]

The map of images.

Definition at line 201 of file creaImageIOMultiThreadImageReader.h.

ImageToLoadPtrPriorityComparator creaImageIO::MultiThreadImageReader::mComparator [protected]

Comparator for the image to load queue.

Definition at line 203 of file creaImageIOMultiThreadImageReader.h.

ImageToLoadPtrIndexer creaImageIO::MultiThreadImageReader::mIndexer [protected]

Indexer for the image to load queue.

Definition at line 205 of file creaImageIOMultiThreadImageReader.h.

IndexedHeap<ImageToLoadPtr, ImageToLoadPtrPriorityComparator, ImageToLoadPtrIndexer> creaImageIO::MultiThreadImageReader::mQueue [protected]

The image to load priority queue.

Definition at line 209 of file creaImageIOMultiThreadImageReader.h.

ThreadedImageReaderListType creaImageIO::MultiThreadImageReader::mThreadedImageReaderList [protected]

Definition at line 213 of file creaImageIOMultiThreadImageReader.h.

int creaImageIO::MultiThreadImageReader::mNumberOfThreadedReadersRunning [protected]

The number of currently running threaded readers.

Definition at line 215 of file creaImageIOMultiThreadImageReader.h.

std::string creaImageIO::MultiThreadImageReader::mRequestedFilename [protected]

For GetImage : the filename requested.

The mutex used to access safely internal data from any thread LG : Removed ! We now use the embedded mutex in User from which we inherit...

Definition at line 222 of file creaImageIOMultiThreadImageReader.h.

vtkImageData* creaImageIO::MultiThreadImageReader::mRequestedImage [protected]

For GetImage : the image requested.

Definition at line 224 of file creaImageIOMultiThreadImageReader.h.

ImageReader* creaImageIO::MultiThreadImageReader::mReader [protected]

If number of threads == 0 then uses an internal non-threaded reader.

Definition at line 227 of file creaImageIOMultiThreadImageReader.h.

IndexedHeap<ImageToLoadPtr, ImageToLoadPtrInversePriorityComparator, ImageToUnloadPtrIndexer> creaImageIO::MultiThreadImageReader::mUnloadQueue [protected]

The image to unload priority queue.

The type of list of images loaded used to unload oldest image when memory limit exceeded

Definition at line 234 of file creaImageIOMultiThreadImageReader.h.

long creaImageIO::MultiThreadImageReader::mTotalMem [protected]

Definition at line 237 of file creaImageIOMultiThreadImageReader.h.

long creaImageIO::MultiThreadImageReader::mTotalMemMax [protected]

Definition at line 238 of file creaImageIOMultiThreadImageReader.h.

The documentation for this class was generated from the following file:

C:/Creatis/creaImageIO/src2/creaImageIOMultiThreadImageReader.h

Generated on Mon Jun 22 10:49:59 2009 for CreaImageIO by

1.5.3


Public Types
enum	EventType { ThreadedReaderStarted, ThreadedReaderStopped, ImageLoaded, ImageUnloaded, Error }
Public Member Functions
	MultiThreadImageReader (int number_of_threads=1)
	Ctor with the number of threads to use.
	~MultiThreadImageReader ()
	Dtor.
bool	Start ()
void	Stop ()
	Stops the reader = stops the threads and delete the images loaded.
void	Request (MultiThreadImageReaderUser *user, const std::string &filename, int priority)
vtkImageData *	GetImage (const std::string &filename)
	(no user callback but image returned)
int	GetMaximalPriority ()
void	OnMultiThreadImageReaderEvent (const std::string &filename, EventType type, vtkImageData *image)
void	MultiThreadImageReaderEventLock ()
void	MultiThreadImageReaderEventUnlock ()
wxMutex &	GetMultiThreadImageReaderUserMutex ()
Protected Types
typedef ImageToLoad *	ImageToLoadPtr
	Type of pointer on an ImageToLoad struct.
typedef std::map < ImageToLoadPtr, vtkImageData *, ImageToLoadPtrFilenameComparator >	ImageMapType
	The type of map of images.
typedef std::vector < ThreadedImageReader * >	ThreadedImageReaderListType
	The type of list of threaded readers.
Protected Member Functions
int	GetMaximalPriorityWithoutLocking ()
void	SignalImageRead (ImageToLoadPtr p, bool purge)
	The callback from threaded readers when an image is read.
void	UpdateUnloadPriority (ImageToLoadPtr p, int priority)
Protected Attributes
ImageMapType	mImages
	The map of images.
ImageToLoadPtrPriorityComparator	mComparator
	Comparator for the image to load queue.
ImageToLoadPtrIndexer	mIndexer
	Indexer for the image to load queue.
IndexedHeap < ImageToLoadPtr, ImageToLoadPtrPriorityComparator, ImageToLoadPtrIndexer >	mQueue
	The image to load priority queue.
ThreadedImageReaderListType	mThreadedImageReaderList
int	mNumberOfThreadedReadersRunning
	The number of currently running threaded readers.
std::string	mRequestedFilename
	For GetImage : the filename requested.
vtkImageData *	mRequestedImage
	For GetImage : the image requested.
ImageReader *	mReader
	If number of threads == 0 then uses an internal non-threaded reader.
IndexedHeap < ImageToLoadPtr, ImageToLoadPtrInversePriorityComparator, ImageToUnloadPtrIndexer >	mUnloadQueue
	The image to unload priority queue.
long	mTotalMem
long	mTotalMemMax
Friends
class	ThreadedImageReader
class	MultiThreadImageReader
Classes
class	ImageToLoad
	Class that represents an image to be loaded. More...
struct	ImageToLoadPtrFilenameComparator
	ImageToLoadPtr comparator on filename (for image map). More...
struct	ImageToLoadPtrIndexer
	ImageToLoadPtr indexer for image queue. More...
struct	ImageToLoadPtrInversePriorityComparator
	ImageToLoadPtr comparator on inverse priority (for image to unload queue). More...
struct	ImageToLoadPtrPriorityComparator
	ImageToLoadPtr comparator on priority (for image queue). More...
struct	ImageToUnloadPtrIndexer
	ImageToLoadPtr indexer for to unload image queue. More...
