wxMaracasMultipleVolumeRendererManagerData Class Reference

#include <wxMaracasMultipleVolumeRendererManagerData.h>

List of all members.

Public Member Functions

 wxMaracasMultipleVolumeRendererManagerData (vtkImageData *vol, std::string dataname="")
 ~wxMaracasMultipleVolumeRendererManagerData ()
void checkInvariant () throw (char *)
void Update ()
vtkProp3D * getProp3D ()
int getId ()
void setId (int propid)
std::string getDataname ()
void setDataname (std::string dataname)
void setVolumeColor (std::vector< double > &greylevel, std::vector< double > &red, std::vector< double > &green, std::vector< double > &blue)
void setVolumeOpacity (std::vector< double > greylevel, std::vector< double > value)
vtkPiecewiseFunction * GetTransferFunction ()
vtkColorTransferFunction * GetColorFunction ()
void changeCompositeMIPFunction (int function) throw (char *)

Protected Attributes

vtkImageData * _vol
std::string _dataname

Private Attributes

int _id
vtkVolumeRayCastCompositeFunction * _compositeFunction
vtkPlanes * _volumePlanes
vtkVolumeRayCastMapper * _volumeMapper
vtkVolumeProperty * _volumeProperty
vtkVolume * _newvol
vtkPiecewiseFunction * _tfun
vtkColorTransferFunction * _ctfun
vtkVolumeRayCastMIPFunction * _MIPFunction

Detailed Description

Definition at line 19 of file wxMaracasMultipleVolumeRendererManagerData.h.

Constructor & Destructor Documentation

wxMaracasMultipleVolumeRendererManagerData::wxMaracasMultipleVolumeRendererManagerData ( vtkImageData *  vol,
std::string  dataname = ""
)

Definition at line 8 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _compositeFunction, _ctfun, _dataname, _MIPFunction, _newvol, _tfun, _vol, _volumeMapper, _volumePlanes, and _volumeProperty.

00008                                                                                                                            {
00009
00010         _vol = vol;
00011         _dataname = dataname;
00012
00013         _tfun = vtkPiecewiseFunction::New();
00014         _ctfun = vtkColorTransferFunction::New();
00015
00016         _volumePlanes  = vtkPlanes::New();
00017         _compositeFunction = vtkVolumeRayCastCompositeFunction::New();
00018         _MIPFunction = vtkVolumeRayCastMIPFunction::New();
00019
00020         _volumeMapper = vtkVolumeRayCastMapper::New();
00021         _volumeMapper->SetVolumeRayCastFunction(_compositeFunction);
00022         _volumeMapper->SetClippingPlanes( _volumePlanes );
00023         _volumeMapper->AutoAdjustSampleDistancesOn();
00024         _volumeProperty = vtkVolumeProperty::New();
00025         _volumeProperty->SetInterpolationTypeToLinear();
00026         //_volumeProperty->ShadeOn();
00027         _volumeProperty->DisableGradientOpacityOn();
00028         _volumeProperty->SetColor(_ctfun);
00029         _volumeProperty->SetScalarOpacity(_tfun );
00030
00031         _newvol = vtkVolume::New();
00032         _newvol->SetMapper(_volumeMapper );
00033         _newvol->SetProperty(_volumeProperty );
00034         _volumeMapper->SetInput( _vol );
00035         _volumeMapper->Update();
00036         _newvol->Update();
00037 }

wxMaracasMultipleVolumeRendererManagerData::~wxMaracasMultipleVolumeRendererManagerData (  )

Definition at line 40 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _compositeFunction, _ctfun, _newvol, _tfun, _volumeMapper, _volumePlanes, and _volumeProperty.

00040                                                                                        {
00041
00042         _tfun->Delete();
00043         _ctfun->Delete();
00044         _volumePlanes->Delete();
00045         _compositeFunction->Delete();
00046         _volumeMapper->Delete();
00047         _volumeProperty->Delete();
00048         _newvol->Delete();
00049
00050 }

Member Function Documentation

void wxMaracasMultipleVolumeRendererManagerData::changeCompositeMIPFunction ( int  function  )  throw (char *)

Definition at line 134 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

00134                                                                                                       {
00135         checkInvariant();
00136         if(function == 0){
00137                 _volumeMapper->SetVolumeRayCastFunction(_compositeFunction);
00138         }else{
00139                 _volumeMapper->SetVolumeRayCastFunction(_MIPFunction);
00140         }
00141
00142 }

void wxMaracasMultipleVolumeRendererManagerData::checkInvariant (  )  throw (char *)

Check if the variables are setted correctly

Definition at line 84 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _compositeFunction, _MIPFunction, and _volumeMapper.

00084                                                                              {
00085         if(!_compositeFunction){
00086                 throw "No composite function initialized";
00087         }
00088         if(!_MIPFunction){
00089                 throw "No MIP function initialized";
00090         }
00091         if(!_volumeMapper){
00092                 throw "No volume mapper initialized";
00093         }
00094 }

vtkColorTransferFunction* wxMaracasMultipleVolumeRendererManagerData::GetColorFunction (  )  [inline]

Definition at line 77 of file wxMaracasMultipleVolumeRendererManagerData.h.

References _ctfun.

Referenced by wxMaracasMultipleVolumeRendererManager::GetColorFunction().

00077                                                     {
00078                 return _ctfun;
00079         }

Here is the caller graph for this function:

std::string wxMaracasMultipleVolumeRendererManagerData::getDataname (  )

Get the filanme

Definition at line 124 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _dataname.

00124                                                                  {
00125         return _dataname;
00126 }

int wxMaracasMultipleVolumeRendererManagerData::getId (  )

return the id from the daat

Definition at line 111 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _id.

Referenced by wxMaracasMultipleVolumeRendererManager::addVolume().

00111                                                      {
00112         return _id;
00113 }

Here is the caller graph for this function:

vtkProp3D * wxMaracasMultipleVolumeRendererManagerData::getProp3D (  )

get the prop3D

Definition at line 105 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _newvol.

Referenced by wxMaracasMultipleVolumeRendererManager::addRemoveActor(), wxMaracasMultipleVolumeRendererManager::addVolume(), and wxMaracasRenderImageTransformation::Refresh().

00105                                                                 {
00106         return this->_newvol;
00107 }

Here is the caller graph for this function:

vtkPiecewiseFunction* wxMaracasMultipleVolumeRendererManagerData::GetTransferFunction (  )  [inline]

Definition at line 73 of file wxMaracasMultipleVolumeRendererManagerData.h.

References _tfun.

Referenced by wxMaracasMultipleVolumeRendererManager::GetTransferFunction().

00073                                                    {
00074                 return _tfun;
00075         }

Here is the caller graph for this function:

void wxMaracasMultipleVolumeRendererManagerData::setDataname ( std::string  dataname  )

Set the filanme

Definition at line 130 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _dataname.

00130                                                                               {
00131         _dataname = dataname;
00132 }

void wxMaracasMultipleVolumeRendererManagerData::setId ( int  propid  )

set data id

Definition at line 117 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _id.

Referenced by wxMaracasMultipleVolumeRendererManager::addVolume().

00117                                                                 {
00118         _id = propid;
00119 }

Here is the caller graph for this function:

void wxMaracasMultipleVolumeRendererManagerData::setVolumeColor ( std::vector< double > &  greylevelcolors,
std::vector< double > &  red,
std::vector< double > &  green,
std::vector< double > &  blue
)

Set Volume Color

Definition at line 54 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _ctfun, and _newvol.

00058 {
00059
00060         _ctfun->RemoveAllPoints();
00061         for(int i = 0; i < greylevelcolors.size();i++){
00062                 _ctfun->AddRGBPoint(greylevelcolors[i], red[i],green[i], blue[i]);
00063                                 //std::cout<<"wxMaracasMultipleVolumeRendererManagerData::setVolumeColor "<<greylevelcolors[i]<<" "<<red[i]<<" "<<green[i]<<" "<<blue[i]<<std::endl;
00064         }
00065         _newvol->Update();
00066 }

void wxMaracasMultipleVolumeRendererManagerData::setVolumeOpacity ( std::vector< double >  greylevel,
std::vector< double >  value
)

Volume Opacity

Definition at line 71 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _newvol, and _tfun.

00071                                                                                                                     {
00072
00073         _tfun->RemoveAllPoints();
00074         for(int i = 0; i < greylevel.size();i++){
00075                 _tfun->AddPoint(greylevel[i], value[i]);
00076                         //std::cout<<"wxMaracasMultipleVolumeRendererManagerData::setVolumeOpacity "<<greylevel[i]<<" "<< value[i]<<std::endl;
00077         }
00078     _newvol->Update();
00079 }

void wxMaracasMultipleVolumeRendererManagerData::Update (  )

Updates volume

Check if the variables are setted correctly

Definition at line 99 of file wxMaracasMultipleVolumeRendererManagerData.cxx.

References _newvol.

Referenced by wxMaracasMultipleVolumeRendererManager::Update().

00099                                                        {
00100          _newvol->Update();
00101 }

Here is the caller graph for this function:

Member Data Documentation

vtkVolumeRayCastCompositeFunction* wxMaracasMultipleVolumeRendererManagerData::_compositeFunction [private]

Definition at line 101 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by checkInvariant(), wxMaracasMultipleVolumeRendererManagerData(), and ~wxMaracasMultipleVolumeRendererManagerData().

vtkColorTransferFunction* wxMaracasMultipleVolumeRendererManagerData::_ctfun [private]

Definition at line 107 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by GetColorFunction(), setVolumeColor(), wxMaracasMultipleVolumeRendererManagerData(), and ~wxMaracasMultipleVolumeRendererManagerData().

std::string wxMaracasMultipleVolumeRendererManagerData::_dataname [protected]

Dataname given by the user (ex. filename)

Definition at line 91 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by getDataname(), setDataname(), and wxMaracasMultipleVolumeRendererManagerData().

int wxMaracasMultipleVolumeRendererManagerData::_id [private]

Definition at line 99 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by getId(), and setId().

vtkVolumeRayCastMIPFunction* wxMaracasMultipleVolumeRendererManagerData::_MIPFunction [private]

Definition at line 108 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by checkInvariant(), and wxMaracasMultipleVolumeRendererManagerData().

vtkVolume* wxMaracasMultipleVolumeRendererManagerData::_newvol [private]

Definition at line 105 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by getProp3D(), setVolumeColor(), setVolumeOpacity(), Update(), wxMaracasMultipleVolumeRendererManagerData(), and ~wxMaracasMultipleVolumeRendererManagerData().

vtkPiecewiseFunction* wxMaracasMultipleVolumeRendererManagerData::_tfun [private]

Definition at line 106 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by GetTransferFunction(), setVolumeOpacity(), wxMaracasMultipleVolumeRendererManagerData(), and ~wxMaracasMultipleVolumeRendererManagerData().

vtkImageData* wxMaracasMultipleVolumeRendererManagerData::_vol [protected]

Prop 3D (data actor)

Definition at line 87 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by wxMaracasMultipleVolumeRendererManagerData().

vtkVolumeRayCastMapper* wxMaracasMultipleVolumeRendererManagerData::_volumeMapper [private]

Definition at line 103 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by checkInvariant(), wxMaracasMultipleVolumeRendererManagerData(), and ~wxMaracasMultipleVolumeRendererManagerData().

vtkPlanes* wxMaracasMultipleVolumeRendererManagerData::_volumePlanes [private]

Definition at line 102 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by wxMaracasMultipleVolumeRendererManagerData(), and ~wxMaracasMultipleVolumeRendererManagerData().

vtkVolumeProperty* wxMaracasMultipleVolumeRendererManagerData::_volumeProperty [private]

Definition at line 104 of file wxMaracasMultipleVolumeRendererManagerData.h.

Referenced by wxMaracasMultipleVolumeRendererManagerData(), and ~wxMaracasMultipleVolumeRendererManagerData().

The documentation for this class was generated from the following files:
